DT55 System
Key Features
- DT55 is designed with refined detailing, delivering a modern aesthetic for living spaces.
- Allows flexible customization of dimensions and design configurations.
- Available in a wide range of colors to suit different preferences and architectural styles.
- Optimized natural light performance: the sturdy aluminum frame enhances daylight penetration, creating bright and well-ventilated interiors.
- Applications: hinged doors, hinged windows, sliding doors, sliding windows, and partitions.
PERFORMANCE
Airtightness: < 12.5 m³/h·m² at pressure P = ±100 Pa
Watertightness: P = 200 Pa for 35 minutes
Wind Load Resistance: Pressure P = ±1000 Pa
Sound Insulation: 25 dB
Security Level: Max Level 2
TECHNICAL SPECIFICATIONS
| Maximum Sash Size: | W 1.5 m x H 2.6 m | Maximum Sash Weight: | 150 kg per door sash 80 kg per window sash |
| Frame Depth: | 55 mm | Visible Width: | 89–121 mm |
| Profile Thickness: | 1.2 / 1.4 / 2.0 mm | Glazing Groove: | 15–27 mm |
| Corner Joint: | 45-degree mitred joint | Corner Joint: | 45-degree mitred joint |
DT55 COLOR PALETTE
Xingfa Gray (PXX)
- Mã màu: PXX
- Công nghệ: Powder coating
- Mô tả:
Dark gray that evokes a warm and sophisticated feel.
Xingfa Brown (PNX)
- Mã màu: PNX
- Công nghệ: Powder coating
- Mô tả:
Dark brown with a reddish undertone, a warm deep tone that conveys a sense of solidity and luxury.
Metallic Gray (M01)
- Mã màu: M01
- Công nghệ: Metallic Coating
- Mô tả:
Dark gray with a subtle shimmer, evoking a bold and vibrant character.
Golden Oak (30)
- Mã màu: 30
- Công nghệ: Wood Grain Coating
- Mô tả:
Bright yellow blended with earthy brown oak grain, creating a naturally warm feel.
Matte Black (PD1)
- Mã màu: PD1
- Công nghệ: Powder coating
- Mô tả:
Matte black, mysterious, luxurious, and refined, perfectly concealing imperfections.
Gray Fir Wood (G01)
- Mã màu: G01
- Công nghệ: Wood Grain Coating
- Mô tả:
Metallic gray blended with soft wood grain, offering a modern sense of depth.
Brown Fir Wood (G02)
- Mã màu: G02
- Công nghệ: Wood Grain Coating
- Mô tả:
Deep wood brown combined with gray undertones, creating a neutral and refined look.
DT55 SYSTEM PRODUCTS
DT55 Casement Door
The DT55 casement door is a common door solution for residential and civil construction projects, suitable for single or multi-panel...
DT55 Casement Window
This is a hinged casement window that allows flexible adjustment of the opening angle. It is suitable for spaces that...
DT55 Sliding Window
The DT55 sliding window uses a horizontal track system, helping to save opening space and optimize usable area, especially suitable...
Molding
The DT55 molding is a finishing detail designed to match the 55 mm system profile, used to cover the gap...
PROJECT
Explore featured projects that incorporate aluminum solutions and a diverse, life-inspired color palette, delivering harmonious and distinctive aesthetics.
